SPC rigid core click · 5.0 mm
5mm SPC Click Flooring (4 mm Rigid Core + 1 mm IXPE)
5mm SPC click flooring is a 5.0 mm floating floor made of a 4.0 mm SPC rigid core with a 1.0 mm IXPE underlay attached to the back at the factory. It clicks together on all four edges. We make it with a 0.30 mm (12 mil) or 0.50 mm (20 mil) wear layer, in three plank sizes, two herringbone sizes and a 305 × 610 mm tile.
- Datasheet per format and wear layer
- Own-brand and private-label orders
- Sample kits on request
- Total thickness
- 5.0 mm (4.0 + 1.0 IXPE)
- Wear layer
- 0.30 or 0.50 mm
- Per 20 ft container
- 2,474–2,937 m²
- Jiaxing and Changzhou, ChinaEcoflors is located in Jiaxing, China, with a production base in Changzhou, China.
- Values tied to a test methodEvery figure in the datasheet table names the standard it was measured to.
- Documents per SKUReports and certificates are matched to the construction, SKU and market you are quoting.
- Your brand or oursPrivate-label cartons and labels, with conditions confirmed per order. Learn More About Ecoflors
Same thickness, different builds
Which 5 mm Floor Are You Quoting?
We make three different floors at 5 mm, each with its own datasheet. Only this one has a rigid core, and only this one counts an attached underlay inside the 5 mm. Check which build a price list means before you compare prices.
-
5mm SPC Click
Core4.0 mm rigid SPCUnderlay1.0 mm IXPE, attachedWear layer0.30 or 0.50 mmThis page
-
5mm Click LVT
Core5.0 mm flexible LVTUnderlayNone attachedWear layer0.30 or 0.50 mm
-
5mm Loose Lay LVT
Core5.0 mm flexible LVTHeld byLaid loose, no click jointWear layer0.55 or 0.70 mm
Specification
5mm SPC Click Specifications & Options
We hold twelve datasheets for this build: six formats, each with a 0.30 mm and a 0.50 mm wear layer. The two sets differ only in the wear layer. Test values and packing figures are the same.
| Item | 5mm SPC Click | Status |
|---|---|---|
| Product type | SPC rigid core click flooring | Datasheet |
| Total thickness | 5.0 mm (0.197 in), measured to ISO 24346, including the attached underlay | Datasheet |
| SPC core thickness | 4.0 mm | Datasheet |
| Attached underlay | 1.0 mm IXPE, laminated to the back at the factory | Datasheet |
| Wear layer | 0.30 mm (12 mil) or 0.50 mm (20 mil), measured to ISO 24340. Both run in all six formats. Neither carries a utilisation class; see the FAQs. | Datasheet |
| Board weight | About 8.1 kg per m², from the datasheet packing basis (4.0 mm SPC at 2,000 kg/m³ plus the IXPE). Use it for freight estimates, not as a tested value. | Calculated |
| Installation | Floating, on the click joint. No adhesive bed. | Datasheet |
| Click system | Uniclic®, i4F or G2 profile, produced under licence. The system is named per SKU in the quotation. | Per SKU |
| Bevel | 4-sided micro bevel, or printed V-bevel | Datasheet |
| Surface finish | UV-cured matte, 4–6 GU gloss | Datasheet |
| Surface texture | Planks and herringbone: wood-grain texture, EIR or crystal embossing. Tile: stone or carpet texture. | Datasheet |
| Utilisation class | Not declared on either wear layer. If your specification names a class, send it and we check what that SKU can be documented to before it goes on a submittal. | Per SKU |
| Decors | Eight popular decors are shown under decors. Which ones run in which format and wear layer is confirmed against your colour list. | Per SKU |
The decision on this page
5 mm Total or 5 mm Core? Reading an SPC Thickness
Our SPC thicknesses are stated as the total, with the 1.0 mm IXPE counted in. So 5 mm here is a 4.0 mm core, and our 6 mm build is the one with a 5.0 mm core. If another quotation says “5 mm SPC + 1 mm IXPE”, compare it with the 6 mm column, not with this page.
| What you are comparing | 5 mm | 6 mm | 7 mm | 8 mm |
|---|---|---|---|---|
| SPC core + attached IXPE | 4.0 + 1.0 mm | 5.0 + 1.0 mm | 6.0 + 1.0 mm | 7.0 + 1.0 mm |
| Wear layers documented | 0.30 or 0.50 mm | 0.50 or 0.55 mm | 0.55 or 0.70 mm | 0.55 or 0.70 mm |
| Board weight, calculated | ≈8.1 kg/m² | ≈10.1 kg/m² | ≈12.1 kg/m² | ≈14.1 kg/m² |
| Floor per 20 ft GP, across six formats | 2,474–2,937 m² | 1,855–2,377 m² | 1,855–1,981 m² | 1,237–1,701 m² |
| Dimensional stability, curling, indentation, castor chair, abrasion group | Same declared values on all four datasheets. See technical performance. | |||
| Utilisation class | Not declared at any of the four thicknesses | |||
5 mm Against 6 mm, Format by Format
| Format | 5 mm | 6 mm | 5 mm carries |
|---|---|---|---|
| 183 × 1220 mm plank | ≈2,893 m² | ≈2,311 m² | 25% more |
| 228 × 1220 mm plank | ≈2,937 m² | ≈2,350 m² | 25% more |
| 228 × 1524 mm plank | ≈2,891 m² | ≈2,377 m² | 22% more |
| 110 × 610 mm herringbone | ≈2,474 m² | ≈1,855 m² | 33% more |
| 150 × 750 mm herringbone | ≈2,835 m² | ≈2,268 m² | 25% more |
| 305 × 610 mm tile | ≈2,813 m² | ≈2,250 m² | 25% more |
At 5 mm most formats fill the container by space before they reach the weight limit. Only the 228 × 1524 mm plank stops at 25 tonnes. That is why a 1 mm thinner core moves the container quantity by a quarter in most formats.
When 5mm SPC Is the Right Call
-
Your range needs a 0.30 mm SPC5 mm
What to check
Of our four SPC thicknesses, 5 mm is the only one with a 0.30 mm datasheet. The 0.50 mm build is also documented at 6 mm, so a range can step up in thickness without changing wear layer.
-
Freight per square metre decides the order5 mm
What to check
The declared test values are the same across 5, 6, 7 and 8 mm, so the thinner core mainly changes weight, height and container quantity. Ask for 5 mm and 6mm SPC click in the same quotation if the specification leaves thickness open.
-
The floor meets another 5 mm floorFloor height
What to check
Same finished height means fewer threshold strips. Measure the existing floor with any separate underlay under it, because our 5 mm already includes its 1.0 mm IXPE.
-
The tender asks for a 0.55 mm or 0.70 mm wear layer6 mm and up
What to check
0.55 mm starts at 6 mm, and 0.70 mm at 7 mm. The 8mm SPC with a 7 mm core carries both. A heavier wear layer is still not a class; send the class if your specification names one.
Construction
Inside the 5 mm SPC Board
The datasheet splits the 5.0 mm into two parts: a 4.0 mm SPC board and a 1.0 mm IXPE underlay attached to its back. The wear layer and the printed decor sit on top of the SPC core and are counted inside the 4.0 mm. The rigid core carries the click joint; the IXPE is the layer that meets the substrate. Density of the SPC core is 1.95–2.05 g/cm³ to ISO 23996, against 1.85–1.95 g/cm³ for our flexible click LVT. That is why a 5 mm SPC board with IXPE weighs less than a 5 mm click LVT board: 1 mm of it is foam.
UV coating
UV-cured matte coat, 4–6 GU.
Wear layer
0.30 mm or 0.50 mm of clear layer over the print.
Printed decor
Wood, stone or carpet look, embossed in register when EIR is ordered.
SPC rigid core
4.0 mm including the layers above. Click profile on all four edges.
Attached IXPE underlay
1.0 mm, laminated at the factory.
We publish no acoustic result for the attached IXPE. Impact sound ratings belong to the whole floor and ceiling build-up, so they come from a test of that assembly. Whether a second underlay can go under an IXPE-backed board depends on the click system; we send the installation instruction for your SKU, including the substrate flatness tolerance, with the order.
Technical performance
Technical Performance & Compliance
Datasheet values for the 5.0 mm SPC build, identical for both wear layers and all six formats. The last column shows whether our 6, 7 and 8 mm SPC datasheets declare the same value. If a test isn’t listed, we haven’t published a result for this build.
Datasheet Values
| Property | Result | Method | 6 / 7 / 8 mm SPC |
|---|---|---|---|
| Overall thickness | 5.0 mm | ISO 24346:2006 | 6.0 / 7.0 / 8.0 mm |
| Wear layer thickness | 0.30 mm (12 mil) or 0.50 mm (20 mil) | ISO 24340:2006 | 0.50–0.70 mm by thickness |
| Density | 1.95–2.05 g/cm³ | ISO 23996:2007 | Same |
| Dimensional tolerance | Length and width within ±0.50 mm | ISO 24342:2018 | Same |
| Squareness | ≤0.15 mm | ISO 24342:2018 | Same |
| Straightness | ≤0.15 mm | ISO 24342:2018 | Same |
| Dimensional stability | ≤0.12 % | ISO 23999:2021 | Same |
| Curling | ≤1.0 mm | ISO 23999:2021 | Same |
| Residual indentation | ≤0.10 mm | ISO 24343-1:2007 | Same |
| Castor chair | No visible damage after 25,000 cycles | ISO 4918:2016 | Same |
| Abrasion group | Group P | EN 660-2 | Same |
| Light stability | Above Grade 6 | ISO 105-B02, Method 3 | Same |
| Stain and chemical resistance | No dulling, surface attack or staining | ISO 26987:2008 | Same |
Compliance by Market
Fire, slip and emissions results are not published here as range-wide ratings. A report covers the construction, thickness, wear layer and decor that was tested, so we match documents to the SKU you are quoting and the market it ships to. Tell us the standard your specification names and we’ll say what we hold for that build and what we don’t. Current certificates are on our certifications page.
Formats and loading
Formats, Packing & Container Loading
Six formats, each in either wear layer. Packing is the same for 0.30 mm and 0.50 mm. Pallets stack up to three high. At this thickness five of the six formats fill the container by space; only the 228 × 1524 mm plank reaches the weight limit first.
| Size | Format | Surface texture options | Packing note |
|---|---|---|---|
| 183 × 1220 mm (7.20 × 48.03 in) | Straight plank | Wood-grain texture, EIR or crystal embossing | 12 pieces per carton, 45 cartons per pallet, 24 pallets. |
| 228 × 1220 mm (8.98 × 48.03 in) | Straight plank | Wood-grain texture, EIR or crystal embossing | 10 pieces per carton, 44 cartons per pallet, 24 pallets. The highest container quantity of the six. |
| 228 × 1524 mm (8.98 × 60.00 in) | Straight plank | Wood-grain texture, EIR or crystal embossing | 8 pieces per carton, 52 cartons on a 980 × 1550 mm pallet, 20 pallets. The only format limited by weight. |
| 110 × 610 mm (4.33 × 24.02 in) | Herringbone, A/B | Wood-grain texture, EIR or crystal embossing | 24 pieces per carton, A and B boards packed separately. Light 13.54 kg cartons, 64 per pallet. More on herringbone vinyl. |
| 150 × 750 mm (5.91 × 29.53 in) | Herringbone, A/B | Wood-grain texture, EIR or crystal embossing | 25 pieces per carton, A and B boards packed separately. 48 cartons on a 990 × 1550 mm pallet, 21 pallets. |
| 305 × 610 mm (12.01 × 24.02 in) | Rectangular tile | Stone texture or carpet texture | 15 pieces per carton, 42 cartons per pallet, 24 pallets. More on stone-look vinyl tile. |
Packing Data per Format
| Format | Pcs per carton | Coverage per carton | Carton gross weight | Cartons per pallet | Coverage per pallet | Pallets per 20 ft GP | Est. coverage per 20 ft GP |
|---|---|---|---|---|---|---|---|
| 183 × 1220 mm plank | 12 | 2.679 m² (28.84 sq ft) | 22.20 kg (48.94 lb) | 45 | 120.560 m² | 24 | ≈2,893 m² (≈31,145 sq ft) |
| 228 × 1220 mm plank | 10 | 2.781 m² (29.94 sq ft) | 23.03 kg (50.77 lb) | 44 | 122.390 m² | 24 | ≈2,937 m² (≈31,618 sq ft) |
| 228 × 1524 mm plank | 8 | 2.779 m² (29.92 sq ft) | 23.02 kg (50.74 lb) | 52 | 144.548 m² | 20 | ≈2,891 m² (≈31,118 sq ft) |
| 110 × 610 mm herringbone | 24 | 1.610 m² (17.33 sq ft) | 13.54 kg (29.86 lb) | 64 | 103.065 m² | 24 | ≈2,474 m² (≈26,625 sq ft) |
| 150 × 750 mm herringbone | 25 | 2.812 m² (30.27 sq ft) | 23.28 kg (51.33 lb) | 48 | 135.000 m² | 21 | ≈2,835 m² (≈30,516 sq ft) |
| 305 × 610 mm tile | 15 | 2.790 m² (30.04 sq ft) | 23.11 kg (50.94 lb) | 42 | 117.211 m² | 24 | ≈2,813 m² (≈30,280 sq ft) |
Loaded cargo gross weight runs from 20,996 kg (110 × 610 mm herringbone) to 24,753 kg (228 × 1220 mm plank). Road limits at some destinations, including many North American inland routes, are lower. We recalculate for your port and inland route before quoting a container quantity, and work out a mixed load from its actual split.
EIR registers the emboss to the print and is ordered per decor. Matching one decor across a plank and a herringbone needs a physical sample before production. See embossed-in-register vinyl.
Decors
Popular Decors
Eight wood decors buyers often ask for on this build, from light sand and greige oaks through taupe grey to dark chestnut. The images are print layouts, not installed floors, so judge colour from a sample rather than a screen.
Amber Brown OakPlank · E88362XL
Mixed Warm OakPlank · E88308L
Natural Greige OakPlank · E88312
Taupe Grey OakPlank · E88222L
Weathered Brown OakPlank · E88171L
Dark Mixed OakPlank · E88023L
Light Sand OakPlank · E88066L
Chestnut BrownPlank · E88289XL
Quote the decor code with your sample or price request. Each decor is its own SKU for the 800 m² minimum, and the formats and wear layers it runs in at 5 mm are confirmed per decor in the quotation. Stone and carpet looks for the tile are sent as samples.
Supply and ordering
Ordering & OEM
Terms we can state before we’ve seen your specification. The rest is confirmed in the quotation.
Ordering Information
- Minimum order
- 800 m² per design or colour. Colours can share a container as long as each one meets its own minimum.
- Custom decor
- From 2,200 m² per decor
- Production lead time
- Generally 35–40 days, reconfirmed when the order is placed
- Quotation basis
- FOB Shanghai is the default quotation basis. Other ports can be coordinated when required.
- Samples
- Sample kits available on request. See sample requests.
- Customs classification
- Commonly declared under HS 3918.10. The importer or customs broker confirms the final code for the destination. HS code guide
- 20 ft container loading
- By format, in the packing table
- Payment terms
- Confirmed in the quotation
OEM & Private Label
5mm SPC click flooring can ship under your brand, with cartons and labels printed to your artwork and your choice of format, wear layer and colours. The OEM and private-label programme covers artwork, approvals and the first-order sequence.
Buyer questions
5mm SPC Click FAQs
Is the 5 mm the SPC board, or the board plus underlay?
Board plus underlay. The 5.0 mm total is a 4.0 mm SPC core with a 1.0 mm IXPE underlay attached. Some suppliers quote the core alone and add the underlay on top, so a “5 mm + 1 mm IXPE” offer matches our 6 mm build, which has a 5.0 mm core. Ask every supplier for core thickness and underlay thickness as separate lines.
Does the attached IXPE give an acoustic rating?
We don’t publish one for this build. Impact sound ratings such as IIC or ΔLw depend on the slab, the ceiling and everything between them, so they come from a test of the whole assembly. If your project needs a rating, send the floor and ceiling build-up and we’ll say what we hold and what would need testing.
Is 5mm SPC rated for commercial areas?
Neither 5 mm SPC datasheet declares a utilisation class, with the 0.30 mm or the 0.50 mm wear layer. Send the class, the traffic and the standard your specification names, and we’ll say whether this build fits or which one does. A class on a submittal has to be backed by a report for the exact SKU.
0.30 mm or 0.50 mm wear layer?
The two builds differ only in the wear layer, 12 mil against 20 mil. Test values, formats and packing are identical, so the 0.50 mm build takes no extra container space. Choose on what your range or tender names; the price difference is shown per format in the quotation.
Does 6 mm SPC perform better than 5 mm?
Not on our datasheets. Dimensional stability, curling, residual indentation, castor chair and abrasion group are declared at the same values for 5, 6, 7 and 8 mm. What the thicker core changes is weight (about 10.1 kg/m² against 8.1 kg/m²), finished floor height, the wear layers on offer and container quantity, which is 18 to 25% lower at 6 mm depending on format.
How is the herringbone packed?
Both herringbone sizes, 110 × 610 mm and 150 × 750 mm, come as A and B boards packed in separate cartons, 24 and 25 pieces per carton. Order A and B in equal quantities unless your layout says otherwise, and allow extra for cutting and setting-out.
Can planks, herringbone and tiles go in the same container?
Yes. Each format, wear layer and colour is its own SKU and meets its own minimum under the ordering terms. Pallet footprints differ by format and most formats fill by space rather than weight, so a mixed load is calculated from your split, not read off one row of the packing table.
Which other SPC thicknesses do you make?
6, 7 and 8 mm, each with a 1.0 mm IXPE counted in the total and its own datasheet, compared with this build above. See 6mm SPC click, 8mm SPC click or the SPC flooring overview.
Quotation
Request a Quote or Sample
Name, company, country, email and an estimated quantity are enough to start. Add any of these and the quotation comes back matched to your build:
- Thickness: 5 mm, or ask us to price 6 mm alongside it
- Wear layer: 0.30 mm or 0.50 mm
- Formats and decor codes
- Click system, class or standard, if your specification names one
- Total area, number of colours, destination port and target delivery month
