5mm Click LVT Flooring (Flexible Core)
5mm Click LVT is the thickest of our three flexible-core click builds: a 5.0 mm floating board with a fibreglass layer inside the LVT core, a click joint on all four edges and a bare back, with no attached underlay. It runs with a 0.30 mm (12 mil) or 0.50 mm (20 mil) wear layer, in three plank sizes, a herringbone and a 305 × 610 mm tile.
- Datasheet per format and wear layer
- Own-brand and private-label orders
- Sample kits on request
- Total thickness
- 5.0 mm (0.197 in)
- Wear layer
- 0.30 or 0.50 mm
- Per 20 ft container
- 2,430–2,481 m²
- Jiaxing and Changzhou, ChinaEcoflors is located in Jiaxing, China, with a production base in Changzhou, China.
- Values tied to a test methodEvery figure in the datasheet table names the standard it was measured to.
- Documents per SKUReports and certificates are matched to the construction, SKU and market you are quoting.
- Your brand or oursPrivate-label cartons and labels, with conditions confirmed per order. Learn More About Ecoflors
Three floors, one thickness
Which 5 mm Floor Are You Quoting?
We make three different floors at 5 mm. The thickness matches; the core and the way the floor stays down don’t, and each one has its own datasheet. If a price list only says “5 mm click”, check which core it means before you compare prices.
-
5mm Click LVT
CoreFlexible LVT, fibreglass layerHeld byClick joint, floatingThis page
-
5mm Loose Lay LVT
CoreFlexible LVT, fibreglass layerHeld byLaid loose, no click joint
-
5mm SPC Click
CoreRigid, mineral-filledHeld byClick joint, floating
Specification
5mm Click LVT Specifications & Options
We hold ten datasheets for this build: five formats, each with a 0.30 mm and a 0.50 mm wear layer. Apart from the wear layer, the two sets carry the same values, down to the packing figures.
| Item | 5mm Click LVT | Status |
|---|---|---|
| Product type | Click LVT, flexible core | Datasheet |
| Total thickness | 5.0 mm (0.197 in), measured to ISO 24346 | Datasheet |
| Wear layer | 0.30 mm (12 mil) or 0.50 mm (20 mil), measured to ISO 24340. Both run in all five formats. The 0.50 mm build does not carry a utilisation class; see the FAQs. | Datasheet |
| Construction | UV coating, wear layer, printed décor film, LVT middle layer carrying a fibreglass layer, LVT bottom layer. No attached underlay. | Datasheet |
| Board weight | About 9.5 kg per m², from the datasheet packing basis (1,900 kg/m³ at 5.0 mm). Use it for freight estimates, not as a tested value. | Calculated |
| Installation | Floating, on the click joint. No adhesive bed. | Datasheet |
| Click system | Uniclic®, i4F or G2 profile, produced under licence. The system is named per SKU in the quotation. | Per SKU |
| Bevel | 4-sided micro bevel, or printed V-bevel | Datasheet |
| Surface finish | UV-cured matte, 4–6 GU gloss | Datasheet |
| Surface texture | Planks and herringbone: wood-grain texture, EIR or crystal embossing. Tile: stone or carpet texture. | Datasheet |
| Utilisation class | Not declared on either wear layer. If your specification names a class, send it and we check what that SKU can be documented to before it goes on a submittal. | Per SKU |
| Decors | Eight wood decors are shown under frequently ordered decors. Which ones run at 5 mm, and in which wear layer, is confirmed against your colour list. | Per SKU |
The decision on this page
What 5 mm Changes, and What It Doesn’t
Our 4, 4.5 and 5 mm click datasheets give identical results for every test they list, from dimensional stability to the castor chair. The extra thickness is board. It adds weight and floor height and it costs container space. It doesn’t move a published performance figure.
| What you are comparing | 4mm Click LVT | 4.5mm Click LVT | 5mm Click LVT |
|---|---|---|---|
| Wear layers documented | 0.30 mm | 0.30 or 0.50 mm | 0.30 or 0.50 mm |
| Board weight | ≈7.6 kg/m² | ≈8.6 kg/m² | ≈9.5 kg/m² |
| Floor per 20 ft GP, across five formats | 3,024–3,144 m² | 2,705–2,813 m² | 2,430–2,481 m² |
| Build-up at thresholds | 4.0 mm | 4.5 mm | 5.0 mm |
| Dimensional stability, curling, indentation, castor chair, abrasion group | Same declared values on all three datasheets. See technical performance. | ||
| Utilisation class | Not declared at any of the three thicknesses | ||
Container Quantity by Format
| Format | 4 mm | 4.5 mm | 5 mm | 5 mm against 4.5 mm |
|---|---|---|---|---|
| 183 × 1220 mm plank | ≈3,047 m² | ≈2,813 m² | ≈2,456 m² | 12.7% less |
| 228 × 1220 mm plank | ≈3,084 m² | ≈2,734 m² | ≈2,430 m² | 11.1% less |
| 228 × 1524 mm plank | ≈3,024 m² | ≈2,812 m² | ≈2,481 m² | 11.8% less |
| 110 × 610 mm herringbone | ≈3,111 m² | ≈2,705 m² | ≈2,435 m² | 10.0% less |
| 305 × 610 mm tile | ≈3,144 m² | ≈2,751 m² | ≈2,438 m² | 11.4% less |
One thing does get easier at 5 mm: the five formats land within 2% of each other per container, and the 228 × 1524 mm plank, which carries the least floor at 4 mm, carries the most at 5 mm. Pick the format on the design and the room, because freight won’t decide it for you.
When 5 mm Is the Right Call
-
Your range or tender names 5 mm5 mm
What to check
If 5 mm is the line on the price ticket or in the tender, this is the build. Both wear layers run in all five formats, so the range can be planned in one thickness.
-
You’re matching a 5 mm floor next door5 mm
What to check
Same finished height means fewer threshold strips and door adjustments. Measure the existing floor, including any underlay, before you rely on the match.
-
Freight per m² decides the order4 or 4.5 mm
What to check
The test values are the same, so thickness is mostly a freight question. 4.5mm Click LVT keeps both wear layers. 4mm Click LVT puts 22 to 29% more floor in a container, in 0.30 mm only.
-
The project needs a declared classOther build
What to check
Thicker is not a class. For commercial areas with daily trolley traffic, look at the glue-down Dryback range, or send us the class and we’ll say which build we can document to it.
Construction
Inside the 5 mm Click Board
All 5.0 mm is vinyl board. The fibreglass layer in the middle carries the dimensional stability, because a floating floor has no adhesive holding it flat.
UV coating
UV-cured matte coat, 4–6 GU.
Wear layer
0.30 mm or 0.50 mm of clear layer over the print.
Décor film
Printed wood or stone design, embossed in register when EIR is ordered.
LVT middle layer with fibreglass
Dimensional stability ≤0.12% to ISO 23999:2021.
LVT bottom layer
Bare back. No IXPE or EVA is laminated to it.
Want an acoustic or comfort layer? It goes in the specification as a separate underlay, and only if the click system on your SKU permits one. Some locking systems don’t. We send the installation instruction for your system, including the substrate flatness tolerance, with the order.
Technical performance
Technical Performance & Compliance
Datasheet values for the 5.0 mm build, identical for both wear layers and all five formats. The right-hand column shows how each value compares with our 4 mm and 4.5 mm click datasheets. If a test isn’t listed, we haven’t published a result for this build.
Datasheet Values
| Property | 5 mm result | Method | 4 / 4.5 mm datasheets |
|---|---|---|---|
| Overall thickness | 5.0 mm | ISO 24346:2006 | 4.0 / 4.5 mm |
| Wear layer thickness | 0.30 mm (12 mil) or 0.50 mm (20 mil) | ISO 24340:2006 | 0.30 mm / 0.30 or 0.50 mm |
| Density | 1.85–1.95 g/cm³ | ISO 23996:2007 | Same |
| Squareness | ≤0.15 mm | ISO 24342:2018 | Same |
| Straightness | ≤0.15 mm | ISO 24342:2018 | Same |
| Dimensional stability | ≤0.12 % | ISO 23999:2021 | Same |
| Curling | ≤1.0 mm | ISO 23999:2021 | Same |
| Residual indentation | ≤0.10 mm | ISO 24343-1:2007 | Same |
| Castor chair | No visible damage after 25,000 cycles | ISO 4918:2016 | Same |
| Abrasion group | Group P | EN 660-2 | Same |
| Light stability | Above Grade 6 | ISO 105-B02, Method 3 | Same |
| Stain and chemical resistance | No dulling, surface attack or staining | ISO 26987:2008 | Same |
Compliance by Market
Fire, slip and emissions results are not published here as range-wide ratings. A report covers the construction, thickness and wear layer that was tested, so we match documents to the SKU you are quoting and the market it ships to. Tell us the standard your specification names and we’ll say what we hold for that build and what we don’t. Current certificates are on our certifications page.
Formats and loading
Formats, Packing & Container Loading
Five formats, each in either wear layer. The packing figures are the same for 0.30 mm and 0.50 mm. Pallets stack up to three high, and weight, not space, sets the container quantity in every format.
| Size | Format | Surface texture options | At 5 mm |
|---|---|---|---|
| 183 × 1220 mm (7.20 × 48.03 in) | Straight plank | Wood-grain texture, EIR or crystal embossing | 11 pieces per carton. 20 pallets per container, one fewer than at 4 and 4.5 mm. |
| 228 × 1220 mm (8.98 × 48.03 in) | Straight plank | Wood-grain texture, EIR or crystal embossing | 8 pieces per carton. The lowest container quantity of the five, 2% below the highest. |
| 228 × 1524 mm (8.98 × 60.00 in) | Straight plank | Wood-grain texture, EIR or crystal embossing | 7 pieces per carton, 60 cartons per pallet, 17 pallets. The highest container quantity at this thickness. |
| 110 × 610 mm (4.33 × 24.02 in) | Herringbone | Wood-grain texture, EIR or crystal embossing | 36 pieces per carton. Allow for cutting and setting-out. More on herringbone vinyl. |
| 305 × 610 mm (12.01 × 24.02 in) | Rectangular tile | Stone texture or carpet texture | 13 pieces per carton. More on stone-look vinyl tile. |
Packing Data per Format
| Format | Pcs per carton | Coverage per carton | Carton gross weight | Cartons per pallet | Coverage per pallet | Pallets per 20 ft GP | Est. coverage per 20 ft GP |
|---|---|---|---|---|---|---|---|
| 183 × 1220 mm plank | 11 | 2.455 m² (26.43 sq ft) | 23.83 kg (52.54 lb) | 50 | 122.793 m² | 20 | ≈2,456 m² (≈26,435 sq ft) |
| 228 × 1220 mm plank | 8 | 2.225 m² (23.95 sq ft) | 21.64 kg (47.71 lb) | 52 | 115.714 m² | 21 | ≈2,430 m² (≈26,156 sq ft) |
| 228 × 1524 mm plank | 7 | 2.432 m² (26.18 sq ft) | 23.61 kg (52.04 lb) | 60 | 145.938 m² | 17 | ≈2,481 m² (≈26,705 sq ft) |
| 110 × 610 mm herringbone | 36 | 2.415 m² (26.00 sq ft) | 23.45 kg (51.69 lb) | 48 | 115.948 m² | 21 | ≈2,435 m² (≈26,209 sq ft) |
| 305 × 610 mm tile | 13 | 2.418 m² (26.03 sq ft) | 23.48 kg (51.76 lb) | 48 | 116.095 m² | 21 | ≈2,438 m² (≈26,242 sq ft) |
Loaded cargo gross weight runs from 23,925 kg (228 × 1220 mm) to 24,249 kg (228 × 1524 mm). Road limits at some destinations, including many North American inland routes, are lower. We recalculate for your port and inland route before quoting a container quantity, and work out a mixed load from its actual split.
EIR registers the emboss to the print and is ordered per decor. Matching one decor across two formats needs a physical sample before production. See embossed-in-register vinyl.
Decors
Frequently Ordered Wood Decors
Eight wood decors that buyers order most often, from pale and sand oaks through two greys to honey and golden tones. Each image is a rendered room next to a close-up of the print; judge colour from a sample, not a screen.
Pale OakPale cream · Ref. 8
Sand OakLight beige · Ref. 3
Rustic Greige OakLight greige · Ref. 4
Whitewashed GreyLight grey · Ref. 9
Weathered GreyGrey · Ref. 2
Honey OakGolden · Ref. 5
Golden OakWarm golden · Ref. 7
Natural OakMid brown · Ref. 17
Quote the reference number with your sample or price request. Each decor is its own SKU for the 800 m² minimum, and the formats and wear layers it runs in at 5 mm are confirmed per decor in the quotation. Stone and carpet-texture looks for the tile are sent as samples.
Supply and ordering
Supply, OEM & Ordering Information
Terms we can state before we’ve seen your specification. The rest is confirmed in the quotation.
Ordering Information
- Minimum order
- 800 m² per design or colour. Colours can share a container as long as each one meets its own minimum.
- Custom decor
- From 2,200 m² per decor
- Production lead time
- Generally 35–40 days, reconfirmed when the order is placed
- Quotation basis
- FOB Shanghai is the default quotation basis. Other ports can be coordinated when required.
- Samples
- Sample kits available on request. See sample requests.
- Customs classification
- Commonly declared under HS 3918.10. The importer or customs broker confirms the final code for the destination. HS code guide
- 20 ft container loading
- By format, in the packing table
- Payment terms
- Confirmed in the quotation
- Documents
- Matched to the SKU, construction and destination market in the quotation
OEM & Private Label
5mm Click LVT can ship under your brand, with cartons and labels printed to your artwork and your choice of format, wear layer and colours. The OEM and private-label programme covers artwork, approvals and the first-order sequence.
Buyer questions
5mm Click LVT FAQs
Is 5mm Click LVT a heavy-commercial floor?
We don’t sell it as one. Neither 5 mm datasheet declares a utilisation class, with either wear layer, and a thicker board is not a class. Send the class, the traffic and the standard your specification names, and we’ll say whether this build fits or which one does. A class on a submittal has to be backed by a report for the exact SKU.
Does 5 mm perform better than 4.5 mm?
Not on our datasheets. Dimensional stability, curling, residual indentation, castor chair and abrasion group are declared at the same values for 4, 4.5 and 5 mm. What 5 mm changes is weight (about 9.5 kg/m²), finished floor height and container quantity, which is 10 to 13% lower than at 4.5 mm depending on format.
Does the 5 mm include an attached underlay?
No. The 5.0 mm is all board: UV coating, wear layer, décor film, an LVT middle layer carrying a fibreglass layer, and an LVT bottom layer. A separate underlay is possible only where the click system on your SKU permits one, and we send that instruction with the order.
What is the difference between 5mm Click LVT, 5mm Loose Lay LVT and 5mm SPC click?
Same thickness, different floors. Click LVT and Loose Lay LVT both have a flexible core with a fibreglass layer; the click version locks board to board, and loose lay has no click joint. SPC has a rigid mineral-filled core and also clicks. Each has its own datasheet: see 5mm Loose Lay LVT and 5mm SPC click.
0.30 mm or 0.50 mm wear layer at 5 mm?
The two builds differ only in the wear layer, 12 mil against 20 mil. Test values, formats and packing are identical, so the 0.50 mm build takes no extra container space. Choose it when your range or tender calls for 20 mil; the price difference is shown per format in the quotation.
Which click system do we get?
Uniclic®, i4F or G2 profile, produced under licence, named per SKU in the quotation. If your market or installers need a particular system, tell us and we’ll confirm what’s available for the format and volume.
Can 5 mm and 4.5 mm go in the same container?
Yes. Each thickness, wear layer, size and colour is its own SKU and meets its own minimum under the ordering terms. Every format reaches the weight limit first, so a mixed load is calculated from the real split, not read off one row of the packing table.
Quotation
Request a Quote or Sample
Name, company, country, email and an estimated quantity are enough to start. Add any of these and the quotation comes back matched to your build:
- Thickness: 5 mm, or ask us to price 4.5 mm alongside it
- Wear layer: 0.30 mm or 0.50 mm
- Format and decor reference numbers
- Click system or class, if your specification names one
- Total area, number of colours, destination port and target delivery month
Prefer to write directly? Email sales@ecoflors.com or message us on WhatsApp +86 134 8633 9267. Other routes are on the contact page.
Request a Sample Kit
Boards of the formats, decors and wear layers you’re considering, before you fix a colour list. Quote the decor reference numbers above.
