Dryback LVT · Glue-down
3mm Dryback LVT Flooring (Glue-Down)
3mm Dryback LVT is our thickest glue-down vinyl build: 3.0 mm total, with a 0.55 mm or 0.70 mm wear layer, bonded to the subfloor with no locking profile and no attached underlay. The 0.70 mm build is declared ISO 10874 Class 34 on our datasheet. It goes to importers, distributors and contractors specifying commercial floors in plank and tile formats.
- Own-brand and private-label orders
- Sample kits on request
- Total thickness
- 3.0 mm (0.118 in)
- Wear layer
- 0.55 / 0.70 mm
- Installation
- Glue-down
- Jiaxing and Changzhou, ChinaEcoflors is located in Jiaxing, China, with a production base in Changzhou, China.
- Values tied to a test methodEvery figure in the datasheet table names the standard it was measured to.
- Documents per SKUReports and certificates are matched to the construction, SKU and market you are quoting.
- Your brand or oursPrivate-label cartons and labels, with conditions confirmed per order. Learn More About Ecoflors
Specification
3mm Dryback LVT Specifications & Options
The build and every option we offer on it, in one table. Anything marked per SKU is confirmed in the quotation once we know the format, wear layer and decor.
| Item | 3mm Dryback LVT | Status |
|---|---|---|
| Total thickness | 3.0 mm (0.118 in), measured to ISO 24346 | Datasheet |
| Wear layer | 0.55 mm (≈22 mil) or 0.70 mm (≈28 mil), measured to ISO 24340 | Datasheet |
| Construction | UV coating, wear layer, printed décor film, LVT middle and bottom layers. No fibreglass layer. | Datasheet |
| Installation | Glue-down over a prepared subfloor. No locking profile, no attached underlay. | Datasheet |
| Edge | 4-sided micro bevel | Datasheet |
| Surface finish | UV-cured matte, 4–6 GU gloss | Datasheet |
| Plank formats | 184.15 × 1219.2 mm (7.25 × 48 in), wood texture 228.6 × 1524 mm (9 × 60 in) | Datasheet |
| Herringbone | 153 × 765 mm (6.02 × 30.12 in) | Datasheet |
| Tile formats | 304.8 × 609.6 mm (12 × 24 in) and 914.4 × 914.4 mm (36 × 36 in) | Datasheet |
| Wear layer by format | Which formats run in 0.55 mm and which in 0.70 mm is confirmed with the quotation. | Per SKU |
| Surface texture by format | Wood texture is listed for the 184.15 × 1219.2 mm plank. Textures for the other formats are confirmed with the decor. | Per SKU |
| Decors | Wood and stone designs from the Dryback range. See the colour range; custom decors are quoted separately. | Per SKU |
| OEM and private label | Available. Minimums and terms are in ordering information. | Per order |
Where 3 mm sits
Is 3mm Dryback LVT Right for Your Project?
Three glue-down builds, three positions. The full comparison sits on the Dryback LVT overview.
-
2mm Dryback LVT
Typical positioningCost-focused programmes
-
2.5mm Dryback LVT
Typical positioningBalanced residential and commercial specification
-
3mm Dryback LVT
Typical positioningHigher-specification commercial projectsThis page
Choosing the thickness
When Does 3mm Make Sense?
Thickness alone doesn’t decide a commercial specification. The class the tender names, the rolling loads and the documents you need matter more. Here is what 3 mm changes compared with our 2.5 mm build, including the part that costs you.
| What you are checking | 3mm Dryback LVT | What it means for the order |
|---|---|---|
| Heaviest wear layer offered | 0.70 mm (≈28 mil). Our 2.5 mm build tops out at 0.55 mm. | The option to take when the tender asks for a class the 0.55 mm build can’t cover. |
| Declared class | Class 34 for the 0.70 mm build, ISO 10582 / ISO 10874 | Ask for the SKU’s test report before the class goes on a submittal. |
| Floor per 20 ft container | ≈4,040 m² in 20 pallets, against ≈4,940 m² for the same plank in 2.5 mm | About 18% less floor per container, so freight per m² rises. Budget for it. |
| Carton weight | 23.54 kg gross for 4.041 m² | Heavier handling per m² on site and in the warehouse. |
Construction
3mm Dryback LVT Construction
Five layers, surface to back. The back is flat so it bonds to the adhesive across its whole area.
UV coating
UV-cured surface coat that sets the matte finish.
Wear layer
Clear layer over the print, 0.55 or 0.70 mm. This is the main choice you make on the 3 mm build.
Décor film
The printed wood or stone design.
LVT middle layer
Main body of the plank or tile.
LVT bottom layer
Flat back that goes into the adhesive. There is no fibreglass sheet in this build.
0.55mm vs 0.70mm Wear Layer
0.55 mm wear layer (≈22 mil)
For offices, hotels and education floors with steady foot traffic. EN ISO 10582 sets 0.55 mm as the minimum wear layer for Class 33. Meeting a minimum is not the same as holding the class, so we confirm the classification for the exact SKU before it goes on a submittal.
0.70 mm wear layer (≈28 mil)
Declared Class 34 (very heavy commercial use) on our datasheet, and the build the performance table below describes. Take it when the tender names Class 34, or when trolleys and rolling loads make the extra wear layer worth the higher cost.
Technical performance
Technical Performance & Compliance
Values from our technical datasheet for the 0.70 mm build, each with the method it was measured to. For 0.55 mm, we send the values for the SKU you are quoting. Where a test isn’t listed here, we haven’t published a result for this build.
Verified Test Data
| Property | Result | Method |
|---|---|---|
| Density | 1.75–1.90 g/cm³ | ISO 23996:2007 |
| Dimensional tolerance | Length and width within ±0.50 mm | ISO 24342:2007 |
| Squareness and straightness | ≤0.20 mm | ISO 24342:2007 |
| Dimensional stability | ≤0.12 % | ISO 23999:2021 |
| Curling | ≤1.2 mm | ISO 23999:2021 |
| Residual indentation | ≤0.10 mm | ISO 24343-1:2007 |
| Peel resistance | >75 N/50 mm | ISO 24345:2006 |
| Flexibility | No cracking in either direction on a 50 mm mandrel | ISO 24344:2008, Method A |
| Castor chair | No visible damage after 25,000 cycles | ISO 4918:2016 |
| Abrasion group | Group P | EN 660-2 |
| Light fastness | Above Grade 6 | ISO 105-B02, Method 3 |
| Stain and chemical resistance | No dulling, surface attack or staining | ISO 26987:2008 |
| Level of use classification | 0.70 mm wear layer: Class 34 0.55 mm: confirmed per SKU | ISO 10582 / ISO 10874 |
Compliance by Market
We don’t publish a fire, slip or emissions rating for this build as a range-wide result. A report only supports the construction, thickness and wear layer that was tested, so we match documents to the SKU you are quoting and the market it is going to. Tell us the standard your specification names and we’ll say what we hold for that build, and what we don’t. Current certificates are listed on our certifications page.
Colour range
3mm Dryback LVT Colours & Designs
Standard decors from the Dryback range. Each one is a separate colour for ordering purposes, and we confirm which run in 3 mm when you send your colour list. For more textures see embossed-in-register vinyl and stone-look vinyl tile.
E88105-004Natural Oak
E88155-001Blonde Ash
E88181-001Urban Loft Grey
E88182-004Honey Birch
E88188-003Nordic White
E88224L-002Smoked Oak
Applications
Recommended Applications
A starting point for the specification, not a substitute for it. Subject to project specification and local requirements.
-
Offices with castor chairs0.55 or 0.70 mm
Project considerations
The class the tender names, and chair castor type. The castor-chair result above is for the 0.70 mm build.
-
Retail floors and shop-in-shop0.70 mm
Project considerations
Trolley and pallet-truck routes, entrance matting and the cleaning regime. Residual indentation is ≤0.10 mm on the datasheet; point loads from shelving are checked separately.
-
Hotel corridors and rooms0.55 or 0.70 mm
Project considerations
Luggage and housekeeping trolleys in corridors, and fire and slip documents for the destination market, matched to the SKU. More on hotel and hospitality flooring.
-
Schools and training buildingsPer project
Project considerations
Classroom furniture movement and the local education authority’s flooring schedule.
-
Care homes and non-clinical healthcare areasPer project
Project considerations
Plank and tile flooring only where the room type allows it. Clinical and wet-clinical rooms often need welded sheet vinyl instead, and the project’s infection-control team decides. See the care home and NHS flooring guide.
Supply and ordering
Supply, OEM & Ordering Information
Terms we can state before we’ve seen your specification. Everything else is confirmed in the quotation.
Ordering Information
- Minimum order
- 800 m² per design or colour. Colours can share a container as long as each one meets its own minimum.
- Custom decor
- From 2,200 m² per decor
- Production lead time
- Generally 35–40 days, reconfirmed when the order is placed
- Quotation basis
- FOB Shanghai is the default quotation basis. Other ports can be coordinated when required.
- Samples
- Sample kits available on request. See sample requests.
- Customs classification
- Commonly declared under HS 3918.10. The importer or customs broker confirms the final code for the destination. HS code guide
- 20 ft container loading
- By format, in the packing table
- Payment terms
- Confirmed in the quotation
- Documents
- Matched to the SKU, construction and destination market in the quotation
Packing & Container Loading
Per-carton and per-pallet figures for the 184.15 × 1219.2 mm plank with a 0.70 mm wear layer. Packing for the other formats and for 0.55 mm is confirmed with the order.
| Format | Pcs per carton | Coverage per carton | Carton size | Carton gross weight | Cartons per pallet | Pallets per 20 ft GP | Est. coverage per 20 ft GP |
|---|---|---|---|---|---|---|---|
| 184.15 × 1219.2 mm plank | 18 | 4.041 m² (43.50 sq ft) | 192.2 × 1229.2 × 56.0 mm (7.56 × 48.39 × 2.20 in) | 23.54 kg (51.89 lb) | 50 (5 per layer × 10 layers) | 20 | ≈4,040 m² (≈43,500 sq ft) |
Road weight limits at some destinations, including many North American inland routes, sit below the load shown here. We recalculate the load for your port and inland route before quoting a container quantity.
OEM & Private Label
We produce 3mm Dryback LVT under your brand: printed cartons and labels to your artwork, your choice of wear layer, format and colours, and custom decors from the minimum above. The OEM and private-label programme covers artwork, approvals and the first-order sequence.
Buyer questions
3mm Dryback LVT FAQs
What is the difference between 3mm and 2.5mm Dryback LVT?
The 3 mm build offers a 0.70 mm wear layer, which the 2.5 mm build doesn’t, and that build is declared Class 34 on our datasheet. The trade-off is less floor per container: about 4,040 m² of the 184.15 × 1219.2 mm plank per 20 ft GP, against about 4,940 m² in 2.5 mm. If the tender is satisfied by a 0.55 mm wear layer, compare both before you decide. The 2.5mm Dryback LVT page has its figures.
Should I choose a 0.55 mm or 0.70 mm wear layer?
Start from the class your specification names, not the thickness. If it names Class 34, quote the 0.70 mm build and ask us for the SKU’s test report. For lower classes, 0.55 mm usually does the job at lower cost, and we confirm its class for the exact SKU.
Is 3mm Dryback LVT the same as 3mm glue-down LVP?
Same product and the same installation. LVP (luxury vinyl plank) is the name North American buyers often use for plank formats; LVT covers planks and tiles. Our 184.15 × 1219.2 mm and 228.6 × 1524 mm planks are what a US or Canadian spec would call 3mm glue-down LVP.
Does 3mm Dryback LVT need an underlay?
No. It is glued directly to a prepared subfloor, and an underlay under a glue-down floor would stop the adhesive bonding. If the project has an acoustic requirement, that is met with a separate acoustic layer the adhesive system approves, and it is specified before ordering.
Which adhesive should the installer use?
One the adhesive manufacturer approves for LVT on your substrate, applied to its trowel and open-time instructions. On commercial jobs, ask the adhesive supplier about rolling loads and underfloor heating too. We don’t name a brand, because the right product depends on the substrate, the site climate and what is sold in your market.
Can 3mm Dryback LVT go into hospitals or care homes?
Only in rooms where the project allows plank or tile flooring. In the UK, NHS flooring guidance sits in HBN 00-10 Part A, and clinical or wet-clinical rooms often need welded sheet vinyl rather than LVT. Confirm the room types with the project’s estates and infection-control teams first. Our care home and NHS flooring guide covers the split.
Can I mix several colours in one container?
Yes. Each colour has to meet its own minimum, listed in the ordering terms. Tell us the split by colour and we’ll work out the load.
Can you send fire and slip test reports for my market?
Send us the market and the standard your specification names. We check which reports cover the exact construction and wear layer being quoted, and tell you plainly if one does not exist yet.
What if the project needs a floating floor instead?
Dryback is glue-down only. For a floating installation, look at Click LVT, or at loose lay vinyl where tiles need to lift out for access.
Quotation
Request a Quote or Sample
Name, company, country, email and an estimated quantity are enough to start. Add any of these in the message and the quotation comes back matched to your build:
- Wear layer (0.55 or 0.70 mm) and format, or ask us to advise
- Class or standard the specification names
- Total area and number of colours
- Destination country and port
- Target delivery month
Prefer to write directly? Email sales@ecoflors.com or message us on WhatsApp +86 134 8633 9267. Other routes are on the contact page.
Request a Sample Kit
Samples of the decors and wear layers you are considering, before you commit to a colour list.
Request Sample KitRequest Quotation & Lead Time
Answered by our sales team, not an automated quote.
