Loose lay LVT · 4.5 mm
4.5mm Loose Lay Vinyl Flooring (LVT)
4.5mm Loose Lay LVT is a 4.5 mm flexible vinyl plank or tile with a fibreglass-reinforced LVT layer and an anti-skid backing. There is no click joint; pieces are laid loose, edge to edge. We make it with a 0.55 mm (22 mil) or 0.70 mm (28 mil) wear layer, in three planks and three tiles, up to a 914 × 914 mm (36 in) square.
- Datasheet per format and wear layer
- Own-brand and private-label orders
- Sample kits on request
- Total thickness
- 4.5 mm (0.177 in)
- Wear layer
- 0.55 or 0.70 mm
- Per 20 ft container
- 2,691–2,819 m²
- Jiaxing and Changzhou, ChinaEcoflors is located in Jiaxing, China, with a production base in Changzhou, China.
- Values tied to a test methodEvery figure in the datasheet table names the standard it was measured to.
- Documents per SKUReports and certificates are matched to the construction, SKU and market you are quoting.
- Your brand or oursPrivate-label cartons and labels, with conditions confirmed per order. Learn More About Ecoflors
Same thickness, different builds
Which Floor Are You Quoting?
Two of our flexible-core floors are made at 4.5 mm, and loose lay also runs at 4 mm and 5 mm. Each has its own datasheet, so check the fixing method and the wear layer on a price list before you compare prices.
-
4.5mm Loose Lay LVT
Held byLaid loose, anti-skid backingWear layer0.55 or 0.70 mmFormats3 planks, 3 tilesThis page
-
4.5mm Click LVT
Held byClick joint, floatingWear layer0.30 or 0.50 mmFormats3 planks, herringbone, tile
-
5mm Loose Lay LVT
CoreFlexible LVT, fibreglass layerHeld byLaid loose, no click joint
Specification
4.5mm Loose Lay LVT Specifications & Options
Twelve datasheets cover this build: six formats, each with a 0.55 mm and a 0.70 mm wear layer. Between the two sets only the wear layer changes. Test values and packing are the same.
| Item | 4.5mm Loose Lay LVT | Status |
|---|---|---|
| Product type | Loose lay LVT, planks and tiles | Datasheet |
| Total thickness | 4.5 mm (0.177 in), measured to ISO 24346 | Datasheet |
| Wear layer | 0.55 mm (22 mil) or 0.70 mm (28 mil), measured to ISO 24340. Both run in all six formats. Neither carries a utilisation class; see the FAQs. | Datasheet |
| Construction | UV coating, wear layer, décor film, LVT layer reinforced with fibreglass, anti-skid backing. No attached underlay. | Datasheet |
| Dual fibreglass | Available on request. Weight, packing and the documents that cover it are confirmed in the quotation. | Per SKU |
| Board weight | About 8.6 kg per m², from the datasheet packing basis (1,900 kg/m³ at 4.5 mm). Use it for freight estimates, not as a tested value. | Calculated |
| Installation | Loose lay. No click joint, and no full-spread adhesive bed. | Datasheet |
| Bevel | 4-sided micro bevel | Datasheet |
| Surface finish | UV-cured matte, 4–6 GU gloss | Datasheet |
| Surface texture | Planks: wood-grain texture, EIR or crystal embossing. Tiles: stone or carpet texture. | Datasheet |
| Utilisation class | Not declared on either wear layer. If your specification names a class, send it and we check what that SKU can be documented to before it goes on a submittal. | Per SKU |
| Decors | Wood looks for the planks; stone, concrete and carpet looks for the tiles. Which decors run at 4.5 mm, and in which format and wear layer, is confirmed against your colour list. | Per SKU |
The decision on this page
4.5 mm Loose Lay Against 4 mm Loose Lay and 4.5 mm Click
Three Ecoflors datasheets, one table. Against 4 mm loose lay, the only differences are the extra 0.5 mm of board and what that weight does to a container. Against 4.5 mm click, it is how the floor stays down, the wear layer and the formats.
| What you are comparing | 4.5mm Loose Lay LVT | 4mm Loose Lay LVT | 4.5mm Click LVT |
|---|---|---|---|
| Total thickness | 4.5 mm | 4.0 mm | 4.5 mm |
| Held down by | Laid loose on an anti-skid backing | Laid loose on an anti-skid backing | Click joint, floating |
| Wear layer | 0.55 or 0.70 mm | 0.55 or 0.70 mm | 0.30 or 0.50 mm |
| Board weight | About 8.6 kg/m² | About 7.6 kg/m² | About 8.6 kg/m² |
| Density | 1.80–1.90 g/cm³ | 1.80–1.90 g/cm³ | 1.85–1.95 g/cm³ |
| Squareness and straightness | ≤0.20 mm, ISO 24342:2007 | ≤0.20 mm, ISO 24342:2007 | ≤0.15 mm, ISO 24342:2018 |
| Formats | 3 planks; 305 × 610, 457 × 457 and 914 × 914 mm tiles | Same six formats | 3 planks; 110 × 610 mm herringbone; 305 × 610 mm tile |
| Floor per 20 ft GP, across all formats | 2,691–2,819 m² | 3,032–3,139 m² | 2,705–2,813 m² |
| Dimensional stability, curling, residual indentation, castor chair, abrasion group | Same declared values on all three datasheets. See technical performance. | ||
| Utilisation class | Not declared on any of the three builds | ||
The 4 mm and 4.5 mm loose lay datasheets declare the same test values. What the extra half millimetre changes is weight: every format hits the container weight limit before it runs out of space, so a 20 ft container carries 7.0 to 12.8% less floor at 4.5 mm, depending on format. The 228.6 × 1524 mm plank loses least, about 7%; the 914 mm tile loses most.
When 4.5 mm Loose Lay Is the Right Call
-
Your range or tender names 4.5 mm loose lay4.5 mm
What to check
Both wear layers run in all six formats with identical packing, so a plank and tile range can be planned in one thickness. If the specification gives total thickness as a minimum rather than a fixed figure, the 4 mm build carries the same datasheet values at a lower freight cost per m².
-
You want 0.55 or 0.70 mm without a click jointLoose lay
What to check
At the same 4.5 mm, our 4.5mm Click LVT is documented to 0.50 mm. The loose lay build carries 0.55 or 0.70 mm with nearly the same container range. Confirm with your installer whether the room needs any perimeter fixing.
-
The range is built around a 9 × 60 in plank228.6 × 1524 mm
What to check
Seven pieces to a carton, 68 cartons on a 970 × 1550 mm pallet, 17 pallets. This is the format where 4.5 mm costs you least container space against 4 mm, about 7%.
-
The design calls for large square tiles457 or 914 mm
What to check
Neither square is on a click datasheet. The 914 mm tile ships three to a carton, 37 cartons stacked on a 940 × 940 mm pallet. If pattern scale matters, ask for a full tile as the sample rather than a cut piece.
-
The project needs a declared classOther build
What to check
Neither the heavier wear layer nor the extra thickness is a class. For areas with daily trolley traffic, look at the glue-down Dryback range, or send us the class and we’ll say which build we can document to it.
Construction
Inside the 4.5 mm Loose Lay Board
A loose-laid floor has no joint and no adhesive holding each piece flat. The fibreglass in the LVT layer carries dimensional stability, and the anti-skid backing sits on the substrate.
UV coating
UV-cured matte coat, 4–6 GU.
Wear layer
0.55 mm or 0.70 mm of clear layer over the print.
Décor film
Printed wood or stone design, embossed in register when EIR is ordered.
LVT layer with fibreglass
Dimensional stability ≤0.12% to ISO 23999:2021. Dual fibreglass on request.
Anti-skid backing
The underside in contact with the substrate. No IXPE or EVA is laminated to it.
The drawing splits layer 4 into an LVT middle layer, the fibreglass layer and an LVT bottom layer, so it shows seven numbers against five datasheet items. Substrate preparation and any perimeter fixing depend on the room and the traffic; ask for the installation instruction for your project before the specification is final.
Technical performance
Technical Performance & Compliance
Datasheet values for the 4.5 mm loose lay build, identical for both wear layers and all six formats. If a test isn’t listed, we haven’t published a result for this build.
Datasheet Values
| Property | Result | Method |
|---|---|---|
| Overall thickness | 4.5 mm | ISO 24346:2006 |
| Wear layer thickness | 0.55 mm (22 mil) or 0.70 mm (28 mil) | ISO 24340:2006 |
| Density | 1.80–1.90 g/cm³ | ISO 23996:2007 |
| Dimensional tolerance | Length and width within ±0.50 mm | ISO 24342:2007 |
| Squareness | ≤0.20 mm | ISO 24342:2007 |
| Straightness | ≤0.20 mm | ISO 24342:2007 |
| Dimensional stability | ≤0.12 % | ISO 23999:2021 |
| Curling | ≤1.0 mm | ISO 23999:2021 |
| Residual indentation | ≤0.10 mm | ISO 24343-1:2007 |
| Flexibility | No cracking in either direction over a 50 mm mandrel | ISO 24344:2008, Method A |
| Castor chair | No visible damage after 25,000 cycles | ISO 4918:2016 |
| Abrasion group | Group P | EN 660-2 |
| Light stability | Above Grade 6 | ISO 105-B02, Method 3 |
| Stain and chemical resistance | No dulling, surface attack or staining | ISO 26987:2008 |
Compliance by Market
Fire, slip and emissions results are not published here as range-wide ratings. A report covers the construction, thickness and wear layer that was tested, so we match documents to the SKU you are quoting and the market it ships to. Tell us the standard your specification names and we’ll say what we hold for that build and what we don’t. Current certificates are on our certifications page.
Formats and loading
Formats, Packing & Container Loading
Six formats cut to whole-inch sizes, each in either wear layer. Packing is the same for 0.55 mm and 0.70 mm. Pallets stack up to three high, and in every format weight, not space, sets the container quantity.
| Size | Format | Surface texture options | Packing note |
|---|---|---|---|
| 184.15 × 1219.2 mm (7.25 × 48 in) | Straight plank | Wood-grain texture, EIR or crystal embossing | 12 pieces per carton, 50 cartons per pallet, 20 pallets. |
| 228.6 × 1219.2 mm (9 × 48 in) | Straight plank | Wood-grain texture, EIR or crystal embossing | 9 pieces per carton, 52 cartons per pallet. |
| 228.6 × 1524 mm (9 × 60 in) | Straight plank | Wood-grain texture, EIR or crystal embossing | 7 pieces per carton, 68 cartons per pallet. The most floor per container of the six, and the lightest carton, 21.35 kg. |
| 304.8 × 609.6 mm (12 × 24 in) | Rectangular tile | Stone texture or carpet texture | 14 pieces per carton, 22 pallets. More on stone-look vinyl tile. |
| 457.2 × 457.2 mm (18 × 18 in) | Square tile | Stone texture or carpet texture | 13 pieces per carton, 36 cartons per pallet, 28 pallets. The heaviest carton, 23.73 kg. More on carpet-pattern vinyl. |
| 914.4 × 914.4 mm (36 × 36 in) | Square tile | Stone texture or carpet texture | 3 pieces per carton, 37 cartons on a 940 × 940 mm pallet, 29 pallets. The least floor per container of the six. |
Packing Data per Format
| Format | Pcs per carton | Coverage per carton | Carton gross weight | Cartons per pallet | Coverage per pallet | Pallets per 20 ft GP | Est. coverage per 20 ft GP |
|---|---|---|---|---|---|---|---|
| 184.15 × 1219.2 mm plank | 12 | 2.694 m² (29.00 sq ft) | 23.54 kg (51.89 lb) | 50 | 134.709 m² | 20 | ≈2,694 m² (≈29,000 sq ft) |
| 228.6 × 1219.2 mm plank | 9 | 2.508 m² (27.00 sq ft) | 21.95 kg (48.38 lb) | 52 | 130.435 m² | 21 | ≈2,739 m² (≈29,484 sq ft) |
| 228.6 × 1524 mm plank | 7 | 2.438 m² (26.25 sq ft) | 21.35 kg (47.07 lb) | 68 | 165.831 m² | 17 | ≈2,819 m² (≈30,345 sq ft) |
| 304.8 × 609.6 mm tile | 14 | 2.601 m² (28.00 sq ft) | 22.74 kg (50.14 lb) | 48 | 124.861 m² | 22 | ≈2,747 m² (≈29,568 sq ft) |
| 457.2 × 457.2 mm tile | 13 | 2.717 m² (29.25 sq ft) | 23.73 kg (52.32 lb) | 36 | 97.826 m² | 28 | ≈2,739 m² (≈29,484 sq ft) |
| 914.4 × 914.4 mm tile | 3 | 2.508 m² (27.00 sq ft) | 21.95 kg (48.38 lb) | 37 | 92.810 m² | 29 | ≈2,691 m² (≈28,971 sq ft) |
Loaded cargo gross weight runs from 23,835 kg (184.15 × 1219.2 mm) to 24,784 kg (228.6 × 1524 mm). Road limits at some destinations, including many North American inland routes, are lower. We recalculate for your port and inland route before quoting a container quantity. Plank pallets and square-tile pallets have different footprints, so a mixed load is worked out from its actual split.
EIR registers the emboss to the print and is ordered per decor. Matching one decor across a plank and a tile needs a physical sample before production. See embossed-in-register vinyl.
Supply and ordering
Ordering & OEM
Terms we can state before we’ve seen your specification. The rest is confirmed in the quotation.
Ordering Information
- Minimum order
- 800 m² per design or colour. Colours can share a container as long as each one meets its own minimum.
- Custom decor
- From 2,200 m² per decor
- Production lead time
- Generally 35–40 days, reconfirmed when the order is placed
- Quotation basis
- FOB Shanghai is the default quotation basis. Other ports can be coordinated when required.
- Samples
- Sample kits available on request. See sample requests.
- Customs classification
- Commonly declared under HS 3918.10. The importer or customs broker confirms the final code for the destination. HS code guide
- 20 ft container loading
- By format, in the packing table
- Payment terms
- Confirmed in the quotation
OEM & Private Label
4.5mm Loose Lay LVT can ship under your brand, with cartons and labels printed to your artwork and your choice of format, wear layer and colours. The OEM and private-label programme covers artwork, approvals and the first-order sequence.
Buyer questions
4.5mm Loose Lay LVT FAQs
Should I choose 4 mm or 4.5 mm loose lay?
The two datasheets declare the same wear layers, formats and test values. The 4.5 mm board weighs about 8.6 kg/m² against 7.6 kg/m², and because every format is weight-limited, a 20 ft container carries 7.0 to 12.8% less floor at 4.5 mm. Choose 4.5 mm when your range, tender or floor build-up names it; otherwise 4 mm costs less to ship per m².
Does 4.5mm loose lay need adhesive?
The datasheet installation method is loose lay: no click joint and no full-spread adhesive bed. Whether a project needs a perimeter or grid fix depends on room size, traffic, sunlight and the substrate. Ask for the installation instruction for your conditions before the specification goes to the installer.
Is 4.5mm Loose Lay LVT rated for commercial areas?
Neither 4.5 mm loose lay datasheet declares a utilisation class, with the 0.55 mm or the 0.70 mm wear layer. Send the class, the traffic and the standard your specification names, and we’ll say whether this build fits or which one does. A class on a submittal has to be backed by a report for the exact SKU.
0.55 mm or 0.70 mm wear layer?
The two builds differ only in the wear layer, 22 mil against 28 mil. Test values, formats and packing are identical, so the 0.70 mm build takes no extra container space. Choose on what your range or tender names; the price difference is shown per format in the quotation.
What does dual fibreglass change?
It adds a second fibreglass reinforcement and is made on request. The datasheet values on this page are for the standard build, so the quotation for a dual-fibreglass SKU states its weight, packing and which reports cover it.
Can planks and square tiles go in the same container?
Yes. Each format, wear layer and colour is its own SKU and meets its own minimum under the ordering terms. Plank pallets run from 970 × 1240 to 970 × 1550 mm, the square tiles sit on 940 × 940 or 950 × 950 mm pallets, and every format reaches the weight limit first. The load is calculated from your split rather than read off one row of the packing table.
Is loose lay made in other thicknesses?
Yes. 5mm Loose Lay LVT has its own page, and a 4 mm build is documented on its own datasheet set. Each thickness has its own datasheet before it goes on your price list. The full range starts from the loose lay LVT overview.
Quotation
Request a Quote or Sample
Name, company, country, email and an estimated quantity are enough to start. Add any of these and the quotation comes back matched to your build:
- Wear layer: 0.55 mm or 0.70 mm
- Formats and decor codes
- Standard or dual fibreglass
- Class or standard, if your specification names one
- Total area, number of colours, destination port and target delivery month
Prefer to write directly? Email sales@ecoflors.com or message us on WhatsApp +86 134 8633 9267. Other routes are on the contact page.
Request a Sample Kit
Samples of the formats, decors and wear layers you’re considering, before you fix a colour list. For the 914 mm tile, ask for a full tile.
