Click LVT range · Flexible core
Click Lock LVT Flooring Manufacturer & Wholesale Supplier
Click lock LVT is luxury vinyl with a flexible core and a locking joint milled into the board edges, laid as a floating floor without an adhesive bed. We make it at 4.0, 4.5 and 5.0 mm, with a fibreglass layer inside the core and no attached underlay, in three plank sizes, a herringbone and a 305 × 610 mm tile.
- 800 m² per design or colour
- Own-brand and private-label orders
- Thicknesses
- 4.0 · 4.5 · 5.0 mm
- Wear layer on datasheet
- 0.30 or 0.50 mm
- Formats
- 3 planks, herringbone, tile
Start with thickness
Three Click LVT Builds
Each build has its own page with the full datasheet, packing per format and decors. The cards show only what tells them apart.
-
4mm Click LVT
The lightest board and the most floor per container. One wear layer.
Wear layer0.30 mmPer 20 ft GP3,024–3,144 m² -
4.5mm Click LVT
The thinnest build offered with a choice of two wear layers.
Wear layer0.30 or 0.50 mmPer 20 ft GP2,705–2,813 m² -
5mm Click LVT
The thickest build, for ranges and tenders that name 5 mm.
Wear layer0.30 or 0.50 mmPer 20 ft GP2,430–2,481 m²
Container ranges cover the five formats at up to 25,000 kg cargo gross weight, from the Ecoflors TDS, version 2026.09.23-R01. Inland road limits are often lower, so the quantity is recalculated for your route before it is quoted.
Definition
What Is Click LVT?
Short answerClick LVT is luxury vinyl flooring with a flexible vinyl core and a mechanical click joint, so boards lock to each other and the floor floats over the subfloor. It is not SPC: SPC also clicks, but its core is rigid and mineral-filled.
The same wood or stone decor often turns up in four different constructions on one price list. What separates them is the core and what holds the floor down, so check both before comparing prices.
| Construction | Core | Held down by | Where to read more |
|---|---|---|---|
| Click LVT | Flexible vinyl, fibreglass layer | Click joint, floating | The three builds above |
| SPC click | Rigid, mineral-filled | Click joint, floating | SPC vs LVT flooring |
| Dryback LVT | Flexible vinyl | Full-spread adhesive | Dryback vinyl flooring |
| Loose lay LVT | Flexible vinyl, fibreglass layer | Laid loose, no click joint | 5mm loose lay LVT |
Range map
What Runs at Which Thickness
One grid for the whole click range, so a range plan can be checked before you open three datasheets. A “Yes” means the option is on the current datasheet for that thickness.
| Option | 4 mm | 4.5 mm | 5 mm | Notes and design pages |
|---|---|---|---|---|
| Wear layer | ||||
| 0.30 mm (12 mil) | Yes | Yes | Yes | Measured to ISO 24340 |
| 0.50 mm (20 mil) | No | Yes | Yes | Heavier layers are not on the click datasheets; ask before planning a range around one |
| Format | ||||
| 183 × 1220 mm plank | Yes | Yes | Yes | 7.20 × 48.03 in |
| 228 × 1220 mm plank | Yes | Yes | Yes | 8.98 × 48.03 in |
| 228 × 1524 mm plank | Yes | Yes | Yes | 8.98 × 60.00 in |
| 110 × 610 mm herringbone | Yes | Yes | Yes | Herringbone vinyl flooring |
| 305 × 610 mm tile | Yes | Yes | Yes | Stone-look vinyl tile |
| Surface and edge | ||||
| Wood grain, EIR or crystal emboss | Yes | Yes | Yes | Planks and herringbone. Embossed-in-register vinyl |
| Stone or carpet texture | Yes | Yes | Yes | Tile format |
| Matte UV finish, 4–6 GU | Yes | Yes | Yes | One gloss level across the range |
| Micro bevel or printed V-bevel | Yes | Yes | Yes | Four sides |
| Joint and build-up | ||||
| Uniclic®, i4F or G2 profile | Yes | Yes | Yes | Produced under licence; the system is named per SKU in the quotation |
| Fibreglass layer in the core | Yes | Yes | Yes | Inside the LVT middle layer |
| Attached IXPE or EVA underlay | No | No | No | A separate underlay only where the click system allows it |
| Declared utilisation class | No | No | No | See where click LVT fits |
Choosing the construction
Where Click LVT Fits, and Where It Doesn’t
-
Residential and multi-unit ranges laid as a floating floorClick LVT
What to plan for
Installers need the substrate tolerance for the specific locking system, and it ships with the order. Decide on any underlay when the range is specified, since not every system accepts one.
-
Hotel room refurbishment programmesPer project
What to plan for
With no class in the brief, click LVT is priced like any other range. With one, send the brief before sampling. The hotel and hospitality flooring page covers the wider programme.
-
Tenders that name a utilisation classDryback LVT
What to plan for
Glue-down builds are where we document classes for trolley and heavy foot traffic. Start from the Dryback range, or send the tender and we’ll name the build.
-
Specifications that call for a rigid coreSPC click
What to plan for
SPC and click LVT share the joint and the floating install, not the core. SPC vs LVT flooring sets out the trade-offs.
Documents and compliance
Where Each Value Is Declared
Buyers check the same items on every click LVT offer. Some are fixed on the datasheet for each thickness; others depend on a test report for one named build, and those are matched to your SKU and market rather than published as range-wide ratings.
Datasheet or Test Report
| Item buyers check | Declared in | How you get it for your order |
|---|---|---|
| Thickness, wear layer, density, squareness | Datasheet, per thickness | Thickness page, then the sheet for your format |
| Dimensional stability, curling, indentation | Datasheet, per thickness | Thickness page |
| Castor chair, abrasion group, light and stain | Datasheet, per thickness | Thickness page |
| Reaction to fire, slip resistance | Test report on a named build | Matched to SKU and market in the quotation |
| Indoor air emissions | Test report or certificate on a named build | Matched to SKU and market in the quotation |
| Locking system | Named per SKU | In the quotation, against your destination |
By Destination Market
Requirements differ by country, and our market pages list what importers there usually ask for: Germany, the United Kingdom, the Netherlands, the United States, Canada and Australia. Certificates we currently hold are on the certifications page.
Specifying a range
How a Click LVT Range Is Specified
The order in which we settle a new click range with an importer or flooring brand. Answers can arrive in any order; the first five are enough for a quotation.
Thickness and wear layer
Check the pairing against the range map above.
Formats
One or several of the five sizes. Every size counts as its own SKU.
Decors
Our references, or a target visual for a custom decor from 2,200 m².
Texture and bevel
Per format, from the surface rows of the range map.
Locking system and destination
Settled together, because the market decides what the system has to cover.
Packaging
Standard export cartons, or cartons and labels printed to your artwork.
Documents
Matched to SKU, construction and market before the order is placed.
Sample approval
Physical boards of the ordered build signed off before production.
Supply and ordering
Ordering Terms for the Click Range
These terms apply to every click LVT build. Anything not listed is confirmed in the quotation.
Ordering Information
- Minimum order
- 800 m² per design or colour. Colours can share a container as long as each one meets its own minimum.
- Custom decor
- From 2,200 m² per decor
- Production lead time
- Generally 35–40 days, reconfirmed when the order is placed
- Quotation basis
- FOB Shanghai is the default quotation basis. Other ports can be coordinated when required.
- Samples
- Sample kits available on request. See sample requests.
- Customs classification
- Commonly declared under HS 3918.10. The importer or customs broker confirms the final code for the destination. HS code guide
- Container loading
- Per format, on each thickness page
- Payment terms
- Confirmed in the quotation
OEM & Private Label
Any build on the range map can ship under your brand, with cartons and labels printed to your artwork. Artwork, approvals and the first-order sequence are covered by the OEM and private-label programme.
Buyer questions
Click LVT Sourcing FAQs
Can one container carry several click LVT thicknesses?
Yes. Every thickness, wear layer, size and colour combination is a separate SKU with its own 800 m² minimum, and SKUs can share a container. Because all click formats hit the weight limit first, the load is worked out from your actual split.
Can we order a wear layer heavier than 0.50 mm?
Not from the current click datasheets. If your range needs one, name it in the enquiry; a new build needs its own datasheet before it belongs on your price list.
Is the locking system licensed for the market we sell into?
The profile is produced under licence, and licences are granted by territory. Give us the destination at the start so the system named on your SKU is settled against that market before the order is placed.
Will the reports we receive cover the exact SKU we order?
Reports are matched to the ordered SKU, construction and market. If the closest report covers a different build, the quotation says so, which leaves the decision with you before production rather than at customs.
Can you develop a decor to match a range we already sell?
Yes, from a target visual or a board of your current floor. Custom decors start at 2,200 m² per decor, and a physical sample is approved before production.
What goes to our installers with the stock?
The installation instruction for the locking system on your SKU: substrate flatness tolerance, perimeter gap and whether a separate underlay is allowed.
Quotation
Price a Click LVT Range
Company, country and an estimated area are enough to start. For a quotation matched to your range, add:
- Thickness and wear layer, from the range map
- Formats and decor references, or a target visual
- Locking system or class, if your specification names one
- Private-label packaging or standard export cartons
- Colours, destination port and target delivery month
Or write to sales@ecoflors.com, or on WhatsApp +86 134 8633 9267. More routes on the contact page.
Request a Sample Kit
Boards from two or three thicknesses side by side are the quickest way to settle which build a range should use.
Request Sample KitRequest Quotation & Lead Time
Answered by our sales team, not an automated quote.
